Rechargeable Lithium Ion Polymer Battery Pack 3.7V 3500mAh 706469
KC IEC62133 approved 3.7 volt 706469 li polymer rechargeable
batteries 3500mAh customized lithium ion polymer battery
Battery using Warnings
- To prevent the possibility of the battery from leaking,heating,fire
please observe the following precautions:
- The soft aluminum packing foil is very easily damaged by sharp edge
parts such as Ni-tabs,pins and needles .
- Do not strike battery with any sharp edge parts.
- Do not immerse the battery in water and seawater
- Do not use and leave the battery near a heat source as fire or
heater
- When recharging, use the battery charger specifically for that
purpose
- Do not reverse the position and negative terminals
- Do not connect the battery to an electrical outlet
- Do not discard the battle in fire or heat it
- The battery tabs are not so stubborn especially for aluminum tab.Do
not bend tab.
- Do not short-circuit the battery by directly connecting the
positive and negative terminal with metal object such wire
- Do not transport and store the battery together with metal objects
such as necklaces,hairpins etc.
- Do not strike or throw the battery.
- Do not directly solder the battery and pierce the battery with a
nail or other sharp object.
3.7V 3500mAh 3.7 v 706469 li ion polymer battery Specification:
| Item | Specification | | Nominal Voltage | 3.7V | | Nominal Capacity | 3500mAh(0.2C discharge) | | Size | 7.0*64*71mm OR as customer request | | Weight | 72.5g | | Composed Type | 1S | | Max Charge Protetion Voltage | 4.2V | | Cut-off Discharge Voltage | 3V | | Charging Current | 0.2C | | Charging Time | 2H | | Charge Method | CC-CV
(constant current and contant voltage ) | | Max Discharge Current | 2C | | Recharge Cycle Life | 500times | | Working Temperature | Charge | 0~45°C,45~85%RH | | Dis-charge | -20~60°C,45~85%RH | | StorageTemperature | One month | -20~60°C,45~85%RH | | and Humidity | Three months | -20~45°C,45~85%RH | | One year | -20~25°C,45~85%RH | | Protection Fuctions | Over charge, Over discharge,
Over load, Short Circuit | | Warranty | 12months |
|
Li polymer battery pack widely used in:
GPS, POS Terminal, Wireless headset, Communication Tool, Heating
Blanket Smart Phone
Learning Tools, Medical Device, Personal Care Scanner Vaccum
Packaging, Lamp, Monitor
Portable DVD, Smart Home, Tablet PC, Pulse Monitoring, Moblie,
Power Bank, Camera
Shenzhen Gold Power Energy have over 1000models lithium polymer
batteries.
Capacity range from 20mAh to 5000mAh, can meet your different kinds
of applications.
Following are some of hot-sale models for your reference.
| Battery Model | Battery Cell Dimension | Battery pack With PCM size | Battery Capacity |
| 302025 | 3.0*20*25mm | 3.2*21*27.5mm | 3.7V 100mAh |
| 302530 | 3.0*25*30mm | 3.2*26*32.5mm | 3.7V 180mAh |
| 401824 | 4.0*18*24mm | 4.2*19*26.5mm | 3.7V 180mAh |
| 402525 | 4.0*25*25mm | 4.2*26*27.5mm | 3.7V 200mAh |
| 483450 | 4.8*34*50mm | 5.0*35*52.5mm | 3.7V 850mAh |
| 502030 | 5.0*20*30mm | 5.2*21*32.5mm | 3.7V 240mAh |
| 502525 | 5.0*25*25mm | 5.2*26*27.5mm | 3.7V 180mAh |
| 503030 | 5.0*30*30mm | 5.2*31*32.5mm | 3.7V 430mAh |
| 523450 | 5.2*34*50mm | 5.4*35*52.5mm | 3.7V 1000mAh |
| 553444 | 5.5*34*44mm | 5.7*35*46.5mm | 3.7V 850mAh |
| 553640 | 5.5*36*40mm | 5.7*37*42.5mm | 3.7V 850mAh |
| 553759 | 5.5*37*59mm | 5.7*38*61.5mm | 3.7V 1400mAh |
| 602030 | 6.0*20*30mm | 6.2*21*32.5mm | 3.7V 300mAh |
| 602240 | 6.0*22*40mm | 6.2*23*42.5mm | 3.7V 500mAh |
| 602535 | 6.0*25*35mm | 6.2*26*37.5mm | 3.7V 500mAh |
| 602663 | 6.0*26*63mm | 6.2*27*65.5mm | 3.7V 1000mAh |
| 603030 | 6.0*30*30mm | 6.2*31*32.5mm | 3.7V 520mAh |
| 603040 | 6.0*30*40mm | 6.2*31*42.5mm | 3.7V 750mAh |
| 603048 | 6.0*30*48mm | 6.2*31*50.5mm | 3.7V 900mAh |
| 603450 | 6.0*34*50mm | 6.2*35*52.5mm | 3.7v 1200mAh |
| 656090 | 6.5*60*90mm | 6.5*60*92.5mm | 3.7V 5000mAh |
| 702040 | 7.0*21*40mm | 7.2*22*42.5mm | 3.7V 500mAh |
| 753048 | 7.5*30*48mm | 7.7*31*50.5mm | 3.7V 1200mAh |
| 803035 | 8.0*30*35mm | 8.2*31*37.5mm | 3.7V 800mAh |
| 855465 | 8.5*54*65mm | 8.5*54*65mm | 3.7V 4000mAh |
| 863040 | 8.6*30*40mm | 8.8*30*42.5mm | 3.7V 1000mAh |
| 904060 | 9*40*60mm | 9.2*40*62.5mm | 3.7V 2500mAh |
| 883760 | 8.8*37*60mm | 9*57*51.6mm | 3.7V 2000mAh |
| 103048 | 10.2*30*48mm | 10.2*30*50.5mm | 3.7V 1500mAh |
| 103040 | 10.2*30*40mm | 10.2*30*42.5mm | 3.7V 1200mAh |
| 114261 | 11*42*61mm | 11*42*63.5mm | 3.7V 3400mAh |
| 122773 | 12*27*73mm | 12*27*75.5mm | 3.7V 2400mAh |
706469 Lithium Polymer battery pack 3.7V 3500mAh li polymer
Rechargeable battery
Standard packaging for 3.7V 7.4V lithium polymer battery pack
Why Choose us:
Technology
- All-weather applicability (-30~60℃)
- Highly safe battery design technology with the newest electrolyte
and separator technology applie
- Full Coverage of Battery Variety: Lithium ion Cylindrical battery,
lithium polymer battery, LiFePO4 battery, Solar Energy Storage
battery pack, square aluminum shell, Primary Battery, etc.
R&D
Experienced R&D team with over 60 engineers and advanced
equipments for supporting OEM and ODM requirements.
Quality Control
Certificates-CE, RoHs, BIS, KC, CB, UL, MSDS, UN38.3, IEC61233 certificated.
Factory Tour:
Shenzhen Gold Power Eenergy Co.,Ltd is one of the leading battery
suppliers in China.
We have started to offer various batteries including Li polymer
battery, Lithium ion battery, LiFePO4 battery,
and customized battery pack since 2001.
