Customize Solar Energy Storage Batteries Household Lithium Iron
phosphate battery pack
Solar Power Storage Batteries 5kwh 7kwh 10kwh Power Wall Energy
Storage System With Blue Tooth
Type | Module | Powerwall | | |
Model | LFP48V50AH | LFP48V100AH | LFP48V150AH | LFP48V200AH |
Battery Capacity [Ah] | 50Ah | 100Ah | 150Ah | 200Ah |
Nominal Battery Energy [kwh] | 2.4kwh | 4.8kwh | 7.2kwh | 9.6kwh |
Max Discharge Current [A] | 50 | 100 | 150 | 200 |
Net Weight | 31Kg | 55kg | 73kg | 92kg |
| 650*485*200 | 650*485*200 | 650*485*200 | 650*485*250 |
Voltage Window (V) | 37.5~55.5 | 37.5~55.5 | 37.5~55.5 | 37.5~55.5 |
Charge Voltage (V) | 53.5~55.5 | 37.5~55.5 | 37.5~55.5 | 37.5~55.5 |
Max. Charge Current(A) | 50A | 50A | 100A | 100A |
Charge Mode | CC-CV | CC-CV | CC-CV | CC-CV |
Scalability | 15 PCS UP to 36kwh / 72 kwh / 108kwh / 144kwh |
Communication | CAN / RS485 / RS232 /DRY CONTACT |
Charge Temperature | 0~5 5℃ |
Certification Standard | IEC62619 /TUV / UN38.3 / UL /CE / ISO90001 |
Wall mounted Solar Energy storage Battery 51.2V 200Ah rechargeable Lifepo4 battery pack
Other hot sale 12V 24v 48V lifepo4 rechargeable battery pack:
| Lead Acid Replacement LiFePO4 Battery Pack |
Voltage | Typical Capacity | Charge | Discharge | Dimension (mm) with case | Weight(Kg) |
| 12V | 8AH | 0.2C-2C | 0.2C-2C | 150*92*65 | 1.25 |
|
| 12V | 10AH | 0.2C-2C | 0.2C-2C | 150*92*65 | 1.6 |
|
| 12V | 12AH | 0.2C-2C | 0.2C-2C | 151*99*95 | 1.8 |
|
| 12V | 50AH | 0.2C-2C | 0.2C-2C | 195*165*175 | 9.5 |
|
| 12V | 100AH | 0.2C-2C | 0.2C-2C | 330*175*220 | 19 |
|
| 12V | 200AH | 0.2C-2C | 0.2C-2C | 525*240*215 | 30 |
|
| 24V | 10AH | 0.2C-2C | 0.2C-2C | 181*77*175 | 3 |
|
| 24V | 30AH | 0.2C-2C | 0.2C-2C | 195*165*175 | 12 |
|
| 24V | 50AH | 0.2C-2C | 0.2C-2C | 330*175*220 | 18 |
|
| 24V | 100AH | 0.2C-2C | 0.2C-2C | 485*175*240 | 32 |
|
| 48V | 10AH | 0.2C-2C | 0.2C-2C | 223*106*175 | 7.5 |
|
| 48V | 50AH | 0.2C-2C | 0.2C-2C | 522*237*215 | 33 |
|
| 48V | 75AH | 0.2C-2C | 0.2C-2C | 522*237*215 | 42 |
|
| 48V | 100AH | 0.2C-2C | 0.2C-2C | 350*540*160 | 52 |
|
Lifepo4 rechargeable battery packs for other applications.
Why Choose us:
Technology
- All-weather applicability (-30~60℃)
- Highly safe battery design technology with the newest electrolyte
and separator technology applie
- Full Coverage of Battery Variety: Lithium ion Cylindrical battery,
lithium polymer battery, LiFePO4 battery, Solar Energy Storage
battery pack, square aluminum shell, Primary Battery, etc.
R&D
Experienced R&D team with over 60 engineers and advanced
equipments for supporting OEM and ODM requirements.
Quality Control
Certificates-CE, RoHs, BIS, KC, CB, UL, MSDS, UN38.3, IEC61233 certificated.
Factory Tour:
Shenzhen Gold Power Eenergy Co.,Ltd is one of the leading battery
suppliers in China.
We have started to offer various batteries including Li polymer
battery, Lithium ion battery, LiFePO4 battery,
and customized battery pack since 2001.
