5KWH 20KWH Solar Energy Storage Batteries Off Grid 3U Rack Cabinet
Solar system storage batteries 51.2V 100AH, 200AH, 400Ah solar backup battery
3U Rack-Mount Battery is made of LiFePo4 battery. It is a new type of backup power supply for the
development of high-tech products. With the advantage of
integration, miniaturization, light, intelligence standardized,
environmental protection, it is a key energy storage element in
modem energy storage systems. Integrate solar inverters and LiFePO4
battery enclosures into a pre-wired modular system for easier and
faster installation.
| Model | LFP-ESS-51.2V |
| Performance | Volt/Capacity | 51.2V 100Ah |
| Battery Energy | 5120Wh |
| Nominal Charge/Discharge Current | 20A |
| Max Charge/Discharge Current | 100A |
| Working Voltage | 43.2~56.16V DC |
| General Specification | Dimension(WXDXH ) | 550*440*130mm(3U) |
| Weight | 47.2Kg |
| Installation | Rack mounted/Wall mounted/Cabinet mounted |
| ChargeTemperature | 0℃~55℃ |
| General Discharge Temperature | -20℃~60℃ |
| IP Rating | IP20 |
| Cell Technology | LiFePO4 |
| Cycle life | 6000 times @80%DOD ,25℃/0.5C |
| Scalability | Max 15 batteries in parallel |
| Communication | Communication | RS485,CAN |
| Display | SOC status indicator.LED indicaton |
| Certification | CB.IEC62619: UL1973: UL9540A: UN38.3: MSDS: |
| CE.EMC.EN61000-6-1/2/3/4:CE-GPSD.EN62619 |
5KWH to 20KWH 3U Rack Cabinet Energy Storage system products
details
5KWH house using backup power supply Usage
Rack mount and wall mount off-grid lifepo4 solarge energy storage
stysem installation
Product Features
The whole module is non-toxic, non-polluting easy installation and
maintenance
LiFeP04 Battery with safety performance, long life time. high power
efficiency
- Battery management system (BMS)
BMS has protection functions including over-discharge, over-charge,
over-current, and high/low temperature protection.
Multiple battery modules can be in parallel for expanding capacity
and power.
RS485/CANBUS/Bluetooth available, supporting remote monitoring,
compatible with global mainstream inverters
Why Choose us:
Technology
- All-weather applicability (-30~60℃)
- Highly safe battery design technology with the newest electrolyte
and separator technology applie
- Full Coverage of Battery Variety: Lithium ion Cylindrical battery,
lithium polymer battery, LiFePO4 battery, Solar Energy Storage
battery pack, square aluminum shell, Primary Battery, etc.
R&D
Experienced R&D team with over 60 engineers and advanced
equipments for supporting OEM and ODM requirements.
Certificates-CE, RoHs, BIS, KC, CB, UL, MSDS, UN38.3, IEC61233 certificated.
Factory Tour:
Shenzhen Gold Power Eenergy Co.,Ltd is one of the leading battery
suppliers in China.
We have started to offer various batteries including Li polymer
battery, Lithium ion battery, LiFePO4 battery,
and customized battery pack since 2001.
